4层框架结构教学楼,土木工程建筑结构毕业设计,长57.6米,宽16.8米,面积3871平方米
浏览量：719
收藏量：0
浏览量：719
收藏量：0
建筑长57.6m,宽16.8m.一榀框架层高4.2m,柱距7.2m,3跨,跨度7.2m,2.4m,7.2m;
一层: 缺
二层:大教室10.8m*7.2m*4间,电脑房10.8m*7.2m*1间,小教室7.2m*7.2m*1间,教师办公室7.2m*7.2m*1间,教师休息室7.2m*7.2m*1间,资料保管室7.2m*7.2m*1间,卫生间7.2m*7.2m*2间;
三层:大教室10.8m*7.2m*4间,电脑房10.8m*7.2m*1间,小教室7.2m*7.2m*1间,教师办公室7.2m*7.2m*1间,教师休息室7.2m*7.2m*1间,资料保管室7.2m*7.2m*1间,卫生间7.2m*7.2m*2间;
四层:大教室10.8m*7.2m*4间,电脑房10.8m*7.2m*1间,小教室7.2m*7.2m*1间,教师办公室7.2m*7.2m*1间,教师休息室7.2m*7.2m*1间,资料保管室7.2m*7.2m*1间,卫生间7.2m*7.2m*2间;
